GruppoSTG Fabbrica 36 Cells - VE136PVTT

155 W
Solar Panel Spec Datasheet

155 W
36 Cells - VE136PVTT
GruppoSTG Fabbrica
Rated Power
155 Wp
Output Warranty
25 Years of 82.5% Output Power
Materials Warranty
12 Years
EnergyPal GruppoSTG Fabbrica Solar Panels 36 Cells - VE136PVTT 155 W
GruppoSTG Fabbrica 155 W vs Other Top Solar Panels
GruppoSTG Fabbrica
Solar Panel Spec Datasheet
155 W
Solar Panel Performance
Rated Power
155 Wp
9.47 %
Voltage at Maximum Power VMPP
18.68 V
Current at Maximum Power IMPP
8.34 A
Open Circuit Voltage VOC
22.99 V
Short Circuit Current ISC
8.91 A
Power Tolerance Positive
+ 3 %
Maximum System Voltage
1000 V
Solar Panels Warranty Terms
Output Warranty
25 Years of 82.5% Output Power
Materials Warranty
12 Years
Solar Panels Thermal Ranges
Operating Temperature Range
-40~85 °C
Temperature Coefficient of Pmax
-0.417 %/°C
Temperature Coefficient of Voc
-0.345 %/°C
Temperature Coefficient of Isc
0.046 %/°C
Solar Panel Attributes
18 kg
Cell Type
Cell Size
156.75×156.75 mm
Cell Count
Glass Type
Tempered, Anti-reflection Coating, Low Iron
Glass Thickness
3.2 mm
Frame Type
Anodized Aluminium Alloy
Junction Box Protection Class
IP 65
Connector Type
Cable Crossection
4 mm2
Cable Length
1000 mm
