Hemao Energy Mono Panel 285W

xm-jy-285W
Solar Panel Spec Datasheet

Model
xm-jy-285W
Series
Mono Panel 285W
Manufacturer
Hemao Energy
Rated Power
285 Wp
Output Warranty
12 Years of 97% Output Power, 25 Years of 97% Output Power
Materials Warranty
25 Years
Hemao Energy
Solar Panel Spec Datasheet
xm-jy-285W
Solar Panel Performance
Rated Power
285 Wp
Efficiency
17.52 %
Voltage at Maximum Power VMPP
32.57 V
Current at Maximum Power IMPP
8.75 A
Open Circuit Voltage VOC
39.86 V
Short Circuit Current ISC
9.21 A
Power Tolerance Positive
+ 5 %
Maximum System Voltage
1500 V
Solar Panels Warranty Terms
Output Warraty
12 Years of 97% Output Power, 25 Years of 97% Output Power
Materials Warraty
25 Years
Solar Panels Thermal Ranges
Operating Temperature Range
-40~85 °C
Temperature Coefficient of Pmax
-0.45 %/°C
Temperature Coefficient of Voc
-0.3 %/°C
Temperature Coefficient of Isc
0.06 %/°C
Solar Panel Attributes
Weight
18.3 kg
Cell Type
Monocrystalline
Cell Size
156×156 mm
Cell Count
60
Glass Thickness
3.2 mm
Frame Type
Anodized Aluminium Alloy
Junction Box Protection Class
IP 67
Connector Type
MC4
Cable Crossection
2 mm2
