Buyer's Guide 2024

Juin Power JP-P-60-265W

Solar Panel Spec Datasheet

EnergyPal Juin Power  Solar Panels JP-P-60-265W JP-P-60-265W
Model
JP-P-60-265W
Series
JP-P-60-265W
Manufacturer
Juin Power
Rated Power
275 Wp
Output Warranty
10 Years of 90% Output Power, 20 Years of 80% Output Power
Materials Warranty
1 Year

The JP-P-60-265W solar panels are compatible with various solar energy systems, including grid-tied and off-grid setups. Homeowners can also pair these panels with energy storage solutions, such as batteries, to store excess energy for use during peak hours or in case of power outages.

Solar Panel Performance

The JP-P-60-265W solar panels have a rated output of 275 Wp and an impressive efficiency of 16.53 %, making them an excellent choice for homeowners looking to harness the power of the sun and reduce their energy costs.

With a maximum system voltage of and a temperature coefficient of , these solar panels can perform optimally even in challenging weather conditions.

Rated Power
275 Wp
Efficiency
16.53 %
Voltage at Maximum Power VMPP
31.05 V
Current at Maximum Power IMPP
8.59 A
Open Circuit Voltage VOC
38.24 V
Short Circuit Current ISC
9.21 A
Power Tolerance Positive
+ 5 %
Maximum Fuse Rating
15 A

Solar Panels Warranty Terms

Output Warranty
10 Years of 90% Output Power, 20 Years of 80% Output Power
Materials Warranty
1 Year

Solar Panels Thermal Ranges

The thermal performance of the JP-P-60-265W solar panels from Juin Power ensures their reliability and efficiency across varying temperature conditions. These panels are designed to operate optimally within a wide operating temperature range of -45~85 °C. Additionally, the temperature coefficients of the panels, such as the Temperature Coefficient of Pmax (), Voc (), and Isc (), play a vital role in determining the panel performance under changing environmental conditions. The carefully engineered thermal attributes of these solar panels contribute to their long-lasting performance and make them an ideal choice for regions with diverse climate patterns

Operating Temperature Range
-45~85 °C

Buy Juin Power JP-P-60-265W Solar Panels

EnergyPal is a dealer for the best Solar Panels and leading energy companies, solar installers and manufacturers of solar and battery storage products. To see our latest deals, and learn about financing and $0 down lease options, please request a quote and we will call you immediately.

Solar Panel Attributes

Weight
19.5 kg
Cell Type
Polycrystalline
Cell Size
156×156 mm
Cell Count
60
Glass Type
Tempered, Anti-reflection Coating, High Transmittance
Glass Thickness
3.2 mm
Frame Type
Anodized Aluminium Alloy
Junction Box Protection Class
IP 65
Connector Type
MC4
Cable Crossection
4 mm2
Cable Length
1000 mm
