Photon Solar Energy SC-315M-60 EU

SC-315M-60 EU
Solar Panel Spec Datasheet

SC-315M-60 EU
SC-315M-60 EU
Photon Solar Energy
Rated Power
315 Wp
Materials Warranty
15 Years
Photon Solar Energy
Solar Panel Spec Datasheet
SC-315M-60 EU
Solar Panel Performance
Rated Power
315 Wp
19.36 %
Voltage at Maximum Power VMPP
33 V
Current at Maximum Power IMPP
9.57 A
Open Circuit Voltage VOC
40.93 V
Short Circuit Current ISC
9.82 A
Power Tolerance Positive
+ 1.5 %
Maximum System Voltage
1500 V
Maximum Fuse Rating
15 A
Solar Panels Warranty Terms
Materials Warranty
15 Years
Solar Panels Thermal Ranges
Operating Temperature Range
-40~85 °C
Temperature Coefficient of Pmax
-0.4 %/°C
Temperature Coefficient of Voc
-0.32 %/°C
Temperature Coefficient of Isc
0.04 %/°C
Solar Panel Attributes
18 kg
Cell Type
Cell Size
156×156 mm
Cell Count
Glass Type
Tempered, Low Iron
Glass Thickness
3.2 mm
Frame Type
Anodized Aluminium Alloy
Junction Box Protection Class
IP 67
Connector Type
Cable Crossection
4 mm2
Cable Length
900 mm
