Senta Energy ST200W-Mono5

ST200M5-72
Solar Panel Spec Datasheet

Model
ST200M5-72
Series
ST200W-Mono5
Manufacturer
Senta Energy
Rated Power
200 Wp
Output Warranty
10 Years of 90% Output Power, 25 Years of 80% Output Power
Materials Warranty
10 Years
Senta Energy
Solar Panel Spec Datasheet
ST200M5-72
Solar Panel Performance
Rated Power
200 Wp
Efficiency
15.67 %
Voltage at Maximum Power VMPP
37.5 V
Current at Maximum Power IMPP
5.34 A
Open Circuit Voltage VOC
44.9 V
Short Circuit Current ISC
5.79 A
Power Tolerance Positive
+ 3 %
Maximum System Voltage
1000 V
Maximum Fuse Rating
10 A
Solar Panels Warranty Terms
Output Warraty
10 Years of 90% Output Power, 25 Years of 80% Output Power
Materials Warraty
10 Years
Solar Panels Thermal Ranges
Operating Temperature Range
-40~+85 °C
Solar Panel Attributes
Weight
13.5 kg
Cell Type
Monocrystalline
Cell Size
125×125 mm
Cell Count
72
Glass Type
Tempered, Low Iron
Glass Thickness
3.2 mm
Frame Type
Anodized Aluminium Alloy
Junction Box Protection Class
IP 65
Connector Type
MC4
Cable Crossection
4 mm2
Cable Length
900 mm
